€47.83 + taxes

€58.35 Tax included

Lock art. 4922530 Multitop Pro ambidextrous mechanical cylinder mortise entry 30 for uprights 2 throws 85 mm centre distance 22 mm front without cylinder.



Cisa Multitop Pro mechanical cylinder lock entry 30 series 49225-30


Lock art. 4922530 Multitop Pro ambidextrous mechanical cylinder mortise entry 30 for uprights 2 throws 85 mm centre distance 22 mm front without cylinder.


Front 22 × 3 mm stainless steel
Deadbolt and latch
Adjustable latch from 11 mm to 17 mm


Technical features:


Drive device via gear system
Box thickness 15 5 mm
Anti-phasing system
Die-cast metal box with zinc coating
Steel lid with zinc coating
Interchangeable latch with nickel-plated roller and bolt
Reversible latch or latch/piston
Provision for additional closures


Included:


Pair of nylon studs art. 0601201
Pair of nylon under-front spacers item 0614165
Threaded pins for fixing extensions
Lock and cylinder fixing screws


Regulations:


Certified according to European standard EN 12209:03
Security: grade 6 (1000 kg lateral push and 600 kg frontal push)
Suitable for doors certified to EN1627:2011 up to resistance class WK/RC 4


Cisa lock




Cisa lock




Dimensions
AND 30
THE 85mm
"
4922530
8015345996002
