€32.05 + taxes

€39.10 Tax included

Lock art. 4622530 mechanical with ambidextrous tilting deadbolt to be inserted, entry 30 for uprights, single throw, centre distance 85 mm, front 22 mm without cylinder.



Cisa mechanical lock with tilting deadbolt, entry 30, series 46225-30


Lock art. 4622530 mechanical with ambidextrous tilting deadbolt to be inserted, entry 30 for uprights, single throw, centre distance 85 mm, front 22 mm without cylinder.


Deadbolt and latch
Adjustable latch and piston from 11 mm to 17 mm
Provision for additional closures
Threaded pins for fixing extensions


Technical features:


Steel box with zinc coating
Stainless steel front
Nickel-plated roller bolt latch and hook
Latch or reversible latch/piston (where provided)
Voltage 12V AC CE
Current consumption 3 1 A


Included:


Pair of nylon studs art. 0601201
Pair of nylon under-front spacers item 0614165
Lock and cylinder fixing screws


Regulations:


Certified according to European standard EN 12209:03
Security: grade 3 (500 kg lateral push and 400 kg bottom push)
Suitable for doors certified to EN1627:2011 up to resistance class WK/RC 2


Cisa lock




Cisa lock




Dimensions
AND 30
"
4622530
8015345085829
